High-performance terabit switches for service aggregation in next-generation data centers; excellent core switches in large-scale campus networks. Become fully programmable Agile Switches with Huawei X1E card upgrade.
Specifications
| Specifications | S9703 | S9706 | S9712 |
| Switching Capacity | 2.88/5.76 Tbit/s | 6.72/14.72 Tbit/s | 8.64/18.56 Tbit/s |
| Packet Forwarding Rate | 2,160 Mpps | 2,880/5,040 Mpps | 3,840/6,480 Mpps |
| Service Slots | 3 | 6 | 12 |
| Wireless Network Management | Native ACAP access control, AP region management, and AP profile management
Radio profile management, unified static configuration, and centralized dynamic management Basic WLAN services, QoS, security, and user management |
||
| User Management | Unified management of wired and wireless users802.1x, MAC, and Portal authentication
Charging based on traffic volume and online duration User authorization based on user groups, domains, and time ranges |
||
| iPCA | Adds marks on service packets to measure the number of lost packets and packet loss ratios in real timeMeasures the number of lost packets and packet loss ratios at the network and device levels on Layer 2 and Layer 3 networks | ||
| SVF | Up to 2K clients (access switches and APs) virtualized into a single device2-level AS structure
Unified management on Huawei and non-Huawei devices
|
||
