Multi-service routing and 10 GE to 40 GE switching capabilities, scalable for large campus networks; card-upgradable for Software-Defined Networking (SDN) and to provide onboard radio frequency Access Controllers (ACs) for wireless communications.
Specifications
| Specifications | S7703 | S7706 | S7712 |
| Switching Capacity | 1.92 Tbit/s | 3.84 Tbit/s, 5.12 Tbit/s | 3.84 Tbit/s, 5.12 Tbit/s |
| Forwarding Performance | 576 Mpps/1,440 Mpps | 1,152 Mpps/2,880 Mpps | 1,344 Mpps/3,360 Mpps |
| Wireless Management | Native AC, wired and wireless convergenceAP access control, AP region management, and AP profile managementRadio profile management, unified static configuration, and centralized dynamic management
Basic WLAN services, QoS, security, and user management AC deployment on different network layers |
||
| User Management | Unified management of wired and wireless users802.1x, MAC, and portal authenticationsCharging based on traffic volume, online duration, and destination addresses (DAA mode)
User authorization based on user groups, domains, and time ranges |
||
| iPCA | Adds marks on service packets in order to measure the number of lost packets and packet loss ratios in real time with zero payloadMeasures the number of lost packets and packet loss ratios at the network and device levels on Layer 2 and Layer 3 networks | ||
| SVF | 64 clients (access switches) and 1K APS virtualized into a single device2-level AS structureUnified management on Huawei and non-Huawei devices | ||
| Open Flow | Multiple controllersUp to 9-level flow tablesGroup table
Meter OpenFlow 1.3 |
||
| Routing | IPv4 static routes, RIP, OSPF, IS-IS, and BGP4IPv6 static routes, RIPng, OSPFv3, IS-Isv6, and BGP4+IPv4/IPv6 equal-cost routes, policy routing, route policy
IPv4 and IPv6 stack Pingv6, Telnetv6, FTPv6, TFTPv6, DNSv6, and ICMPv6 IPv4-to-IPv6 transition technologies, such as IPv6 manual tunnel, 6to4 tunnel, ISATAP tunnel, GRE tunnel, and IPv4-compatible automatic tunnel |
||
| Virtualization | CSS horizontal virtualizationSVF vertical virtualization
|
||
