Wall-mounted, gigabit 802.11ac Access Points (APs) in a sleek design with built-in antennas, indicator lights hidden behind a sliding panel, and software upgrade technologies. Installs easily and cleanly on an 86 mm plate.
Specifications
| Specifications | AP2030DN |
| Dimensions (H x W x D) | 140 mm x 86 mm x 41.5 mm |
| Power Input | DC: 12V ± 10%
PoE: -48V in compliance with IEEE 802.3af/at |
| Maximum Power Consumption | 8.7W |
| Operating Temperature | 0°C to +40°C |
| Antenna Type/Antenna Gain |
Built-in antenna/2.4 GHz: 2 dBi, 5 GHz: 3 dBi |
| Maximum Number of Concurrent Users | ≤ 64 |
| Maximum Transmit Power | 21 dBm (combined power) |
| MIMO: Spatial Streams | 2 x 2:2 |
| Wireless Protocols | 802.11a/b/g/n/ac |
| Highest Rate | 1.167 Gbit/s
|
