Huawei’s cost-effective 802.11n/ac AP4030DN and AP4130DN Access Points (APs) provide gigabit access to greatly improve a user’s experience on wireless networks. This series of APs is best suited for small and medium enterprises, airports and stations, sports stadiums, cafes, and entertainment centers.
Specifications
| Specifications | AP4030DN | AP4130DN |
| Dimensions (H x W x D) | 180 mm x 180 mm x 39.5 mm | 180 mm x 180 mm x 39.5 mm |
| Power Input | 12V DC ± 10%
PoE: -48V DC (in compliance with IEEE 802.3af/at) |
12V DC ± 10%
PoE: -48V DC (in compliance with IEEE 802.3af/at) |
| Maximum Power Consumption | 10.2W | 10.2W |
| Operating Temperature | 0℃ to +45℃ | 0℃ to +45℃ |
| Antenna Type/Antenna Gain | Built-in antenna/2.4 GHz: 4 dBi, 5 GHz: 6 dBi | Removable RP-SMA antenna/2.4 GHz: 3.5 dBi, 5 GHz: 4 dBi |
| Maximum Number of Concurrent Users | ≤ 256 | ≤ 256 |
| Maximum Transmit Power | 23 dBm | 23 dBm |
| MIMO: Spatial Streams | 2 x 2:2 | 2 x 2:2 |
| Wireless Protocols | 802.11a/b/g/n/ac | 802.11a/b/g/n/ac |
| Highest Rate | 1.167 Gbit/s | 1.167 Gbit/s |
