Huawei AP6010 series APs boost the coverage and quality of WLAN connections for delay-sensitive services and high-bandwidth applications, such as VoWLAN and multimedia streaming. Offering both high capacity and pervasive coverage, AP6010 series APs work best in simple building structures with open/semi-open wireless environments that have a high density of users needing quality wireless services — scenarios that include enterprise offices, campuses, hospitals, large shopping malls, and exhibition centers.
Specifications
| Specifications | AP6010DN-AGN | AP6010SN-GN |
| Dimensions (H x W x D) | 180 mm x 180 mm x 50 mm | 180 mm x 180 mm x 50 mm |
| Power Input | 12V DC ± 10%
PoE: –48V DC (in compliance with IEEE 802.3af/at) |
12V DC ± 10%
PoE: –48V DC (in compliance with IEEE 802.3af/at) |
| Maximum Power Consumption | 10.2W | 6.5W |
| Operating Temperature | –10℃ to +50℃ | –10℃ to +50℃ |
| Antenna Type/Antenna Gain | Built-in antenna/2.4 GHz: 4 dBi, 5 GHz: 5 dBi | Built-in antenna/4 dBi |
| Maximum Number of Concurrent Users | ≤ 128 | ≤ 128 |
| Maximum Transmit Power | 23 dBm (combined power) | 23 dBm (combined power) |
| MIMO: Spatial Streams | 2 x 2:2 | 2 x 2:2 |
| Radio Protocols | 802.11a/b/g/n | 802.11b/g/n |
| Highest Rate | 600 Mbit/s | 300 Mbit/s |
