Huawei AP6310SN-GN AP is ideal for wide-coverage WLAN scenarios with high signal attenuation, such as hotels and office buildings. This 802.11n Fit AP delivers robust wireless access in distributed AP/feeder networks, combined 2G/3G networks, WLAN over CATV (WoC), and WLAN over Ethernet (WoE). In WoC and WoE scenarios, the AP6310SN-GN works with existing CATV or Ethernet cable resources to transmit WLAN signals — no wall drilling or extra cabling is required.
Specifications
| Specifications | AP6310SN-GN |
| Dimensions (H x W x D) | 150 mm x 130 mm x 35 mm |
| Power Input | 12V DC ± 10%
PoE: −48V DC (in compliance with IEEE 802.3af/at) |
| Maximum Power Consumption | 8.3W |
| Operating Temperature | −10℃ to +50℃ |
| Antenna Type/Antenna Gain | Built-in antenna/2.4 GHz: 2 dBi, 5 GHz: 2.5 dBi |
| Maximum Number of Concurrent Users | ≤ 128 |
| Maximum Transmit Power | 27 dBm |
| MIMO: Spatial Streams | 1 x 1:1 |
| Radio Protocols | 802.11b/g/n |
| Maximum Speed | 150 Mbit/s |
